The Mosmatic 54.653 Swivel is a rugged 360° rotary union engineered for high-pressure cleaning and fluid systems operating up to 5000 psi. It features 3/8" NPTF female inlet and 3/8" NPTM male outlet connections, offering full-thread compatibility for seamless integration with hoses, guns, lances, and other pressure components.

With its nickel-plated brass body, stainless steel internal components, and precision-sealed ball bearings, the 54.653 ensures smooth, reliable rotation and long service life in the most demanding environments.

Applications

• Professional pressure washer systems

• Hose reels and lances

• Car wash bays and booms

• High-pressure surface cleaners

• Industrial cleaning and fluid transfer setups

Features

• 360° continuous rotation

• Pressure rated up to 5000 psi

• 3/8" NPTF (F) inlet x 3/8" NPTM outlet

• Durable and compact with smooth bearing system

• Protects hoses from twisting and wear

• Corrosion-resistant materials and sealed internal design

Specs

Part Number: 54.653
Max Pressure: 5000 psi
G1 (Female Inlet): 3/8" NPTF
G2 (Male Outlet): 3/8" NPTM
Nominal Width (NW): 3/8"
Spanner Size (SW1): 0.63
Length L1: 2.87"
Total Length (L2): 4.33"
Rotating Section (L3): 0.51"
Diameter D1: 2.17"
Diameter D2: 0.79
Weight: 2.56 oz
Body Material: Nickel-plated brass
Internal Material: Stainless steel
Seal Type: O-ring (NBR or Viton)
Temperature: Up to 250°F

The Mosmatic 54.163 Swivel is a high-pressure 360° rotary union built for demanding industrial and cleaning applications. With a 3/8" NPTF female inlet and a G3/8" male outlet, this swivel is optimized for systems that require robust, leak-free rotation and compatibility with mixed-thread components.

Designed to withstand pressures up to 5000 psi, the 54.163 helps prevent hose twisting, extends hose life, and enhances operator comfort. Its nickel-plated brass body, stainless steel internal parts, and precision ball bearings ensure exceptional durability and smooth operation even under continuous high-pressure use.

Applications

• Pressure washer hose reels and wands

• Car wash booms and lances

• Surface cleaners and mobile wash equipment

• Industrial fluid and air handling systems

• Any system requiring smooth 360° swivel function

Features

• Full 360° rotation for tangle-free operation

• Pressure rated up to 5000 psi

• 3/8" NPTF inlet x G3/8" M outlet

• Durable, corrosion-resistant construction

• Compact and lightweight (2.56 oz)

• Internal stainless steel components and sealed bearing system

Specs

Part Number: 54.163
Max Pressure: 5000 psi
G1 (Female Inlet): 3/8" NPTF
G2 (Male Outlet): G3/8" M
Nominal Width (NW): 1/4"
Spanner Size (SW1): 0.63
Length L1: 2.87"
Total Length (L2): 4.29"
Rotating Section (L3): 0.47"
Diameter D1: 2.17"
Diameter D2: 0.79
Weight: 2.56 oz
Body Material: Nickel-plated brass
Internal Material: Stainless steel
Seal Type: O-ring (NBR or Viton depending on configuration)
Temperature: Up to 250°F

The Mosmatic 54.063 Swivel is a high-performance rotary union designed for use in high-pressure cleaning and fluid handling systems up to 5000 psi. This swivel features a 1/4" NPTF female inlet and a G3/8" male outlet, making it an ideal solution when connecting components with mixed thread types.

The 360° swivel action helps reduce hose twisting, operator fatigue, and wear on connected components. Manufactured with a nickel-plated brass body, stainless steel internal components, and high-quality ball bearings, it ensures smooth rotation and extended service life under demanding conditions.

Applications

• Pressure washer spray guns and lances

• High-pressure hose reels

• Car wash booms and bays

• Mobile cleaning systems

• Industrial wash-down and fluid transfer lines

Features

• 360° full-rotation swivel

• Rated up to 5000 psi

• Compact and lightweight at only 2.54 oz

• Mixed threading: 1/4" NPTF (F) x G3/8" (M)

• Smooth operation with precision bearings

• Durable nickel-plated brass housing

• Sealed system for long-term performance

Specs

Part Number: 54.063
Max Pressure: 5000 psi
G1 (Female Inlet): 1/4" NPTF
G2 (Male Outlet): G3/8" M
Nominal Width (NW): 1/4"
Spanner Size (SW1): 0.63
Length L1: 2.80"
Total Length (L2): 4.21"
Rotating Section (L3): 0.47"
Diameter D1: 2.17"
Diameter D2: 0.79
Weight: 2.54 oz
Body Material: Nickel-plated brass
Internal Material: Stainless steel
Seal Type: O-ring (NBR or Viton depending on application)
Temperature: Up to 250°F

The Mosmatic 54.663 Swivel is a professional-grade 360° rotary union engineered for high-pressure systems up to 5000 psi. With a 3/8" NPTF female inlet and a G3/8" male outlet, this model is ideal for setups requiring compatibility between NPT and BSPP (G-thread) components.

This swivel is widely used in pressure washer lances, reels, and rotating arms, where its sealed bearing system, nickel-plated brass housing, and stainless steel internal parts ensure smooth, long-lasting rotation—even under continuous use in harsh environments.

Applications

• Pressure washer guns and reels

• Car wash systems and bays

• Hose booms and rotating connections

• Surface cleaners and spray wands

• Industrial fluid systems with mixed-thread connections

Features

• Full 360° rotation

• Rated up to 5000 psi

• 3/8" NPTF (F) inlet x G3/8" (M) outlet

• Lightweight and compact (2.56 oz)

• Nickel-plated brass body with stainless steel internals

• Reduces hose wear and prevents kinks

• Maintenance-free, sealed bearing design

Specs

Part Number: 54.663
Max Pressure: 5000 psi
G1 (Female Inlet): 3/8" NPTF
G2 (Male Outlet): G3/8" M
Nominal Width (NW): 3/8"
Spanner Size (SW1): 0.63
Length L1: 2.87"
Total Length (L2): 4.29"
Rotating Section (L3): 0.47"
Diameter D1: 2.17"
Diameter D2: 0.79
Weight: 2.56 oz
Body Material: Nickel-plated brass
Internal Material: Stainless steel
Seal Type: O-ring (NBR or Viton depending on application)
Temperature: Up to 250°F

The Mosmatic 54.051 Swivel is a compact, high-performance rotary union designed for smooth, leak-free rotation in low- to high-pressure systems. With 1/4" NPTF (female) inlet and 1/4" NPTM (male) outlet ports, this swivel allows full 360° rotation, reducing hose wear and minimizing operator fatigue in spray and pressure applications.

Its robust design and precision-machined components ensure long service life, even under continuous operation. Ideal for pressure washing, automated systems, or any rotating connection needing reliability and durability.

Applications:

• Pressure washer hoses and wands

• High-pressure spray equipment

• Rotating arms and booms

• Car wash and industrial cleaning setups

Features:

• 360° rotary swivel

• Connection: 1/4" NPTF (inlet) x 1/4" NPTM (outlet)

• Compact, lightweight construction

• Precision-engineered for smooth rotation

• Reduces hose kinking and improves handling

Specs

Part Number: 54.051
G1 (Female Inlet): 1/4" NPTF
G2 (Male Outlet): 1/4" NPTM
Nominal Width (NW): 1/4"
Spanner Size (SW1): 0.63
Length L1: 2.80"
Length L2 (Total Length): 4.21"
Length L3 (Rotating Section): 0.47"
Diameter D1 (overall diameter): 2.17"
Diameter D2: 0.79"
Weight: 2.54 oz
