Mosmatic

Ensure long-lasting, high-performance operation of your Mosmatic swivel with the Mosmatic Seal Kit 36.905 - NW ¼”. This premium carbide seal kit is designed for DYL, DYG, DYF, DYW, DYCI, DYDI, DYT, and DYU Swivels with a nominal width of ¼ inch. Engineered for high-pressure and high-RPM applications, it’s ideal for surface cleaners, wall cleaners, tire cleaners, parts washers, and self-rotating systems. Built to withstand intense operating conditions, this kit ensures leak-free, durable swivel performance in professional cleaning environments.

The Mosmatic 52.903 Break-Away Fitting is a safety-focused connector designed to prevent equipment damage by disconnecting under excessive force. Constructed from brass with a nickel-plated finish, this fitting provides both durability and corrosion resistance in demanding high-pressure environments.

With a thread inlet of 3/8" NPTM and an outlet of 3/8" NPTF, it’s rated for up to 5800 PSI, making it ideal for professional car wash and pressure washer systems where safety and reliability are essential.

Applications

• Self-serve and automatic car wash bays

• High-pressure pressure washer systems

• Spray guns, hoses, and boom connections

• Industrial cleaning equipment requiring safety disconnects

Key Features

• Material: Brass, nickel-plated for corrosion resistance

• Thread In: 3/8" NPTM | Thread Out: 3/8" NPTF

• Max Pressure Rating: 5800 PSI

• Designed to break away under force to protect equipment

• Ideal for safety-critical installations

• Supports long-term durability in wet, high-pressure environments

Specs

Material Type: Brass, nickel-plated

Max Pressure Rating: 5800 PSI

Thread IN: 3/8" NPTM

Thread OUT: 3/8" NPTF

Weight: 0.9 lbs

The Mosmatic DGG Swivel 33.351 (90 Degrees) is a high-precision, brass, nickel-plated swivel designed for high-pressure, self-rotating cleaning applications. Built to perform in demanding environments like tire washers, parts cleaning systems, and industrial surface cleaners, this swivel ensures longevity and efficiency.

Featuring a compact 90-degree angle design, it includes a triple bearing system—two radial ball bearings and one thrust ball bearing—for smooth, reliable operation. The swivel is sealed with a dependable O-ring NBR system, with optional upgrades to EPDM or FKM for chemical resistance. Designed for corrosion resistance, easy bulkhead mounting, and maintenance-free use, the 33.351 delivers long-term durability and exceptional precision.

Applications

• High-pressure rotating cleaning systems

• Tire and underbody cleaning equipment

• Parts washers and degreasers

• Industrial wash stations

• Surface cleaners and sprayers

Key Features

• Design: 90° angled swivel

• Material: Brass, nickel plated

• Seal System: O-ring NBR (optional EPDM or FKM)

• Bearing Type: Triple bearing (2x radial, 1x thrust)

• Thread IN (G1): 1/4” NPTF

• Thread OUT (G2): 1/4” NPTM

• Overall Diameter: 1.34”

• Overall Length: 2.71”

• Nominal Width (NW): 1/4”

• Wrench Size (SW): 0.87”

• Max Pressure: 4000 PSI

• Max RPM: 1000

• Max Temperature:

  • 90°F at 1000 RPM

  • 250°F at 30 RPM

• Mounting Style: Bulkhead

• Maintenance: Maintenance-free

Specs

Pressure: 4000 psi (27.5 MPa)

Temperature: 90°F at 1000 RPM, 250°F at 30 RPM

RPM: max 1,000 rpm

Material Type: Brass, Nickel plated

Inner Part: Stainless steel

Seal: O-ring NBR (optional: EPDM or FKM)

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 3/8” NPTF

Thread Out: G2 1/4” NPTM

Nominal Width (NW): 1/4”

Wrench Size 1 (SW1): 0.87"

Wrench Size 2 (SW2): 0.67"

Wrench Size 3 (SW3): 1.34"

Diameter (D) (overall diameter): 1.34"

Length 1 (L1) (overall length) : 2.71"

Length 2 (L2): 0.43"

Weight: 7.8 oz

The Mosmatic 70.016 High-Pressure Quick Connect Coupling is designed for efficient, secure connections in professional pressure washing systems. Constructed from high-grade stainless steel, it offers superior durability and corrosion resistance in high-pressure environments.

This male-threaded coupling allows for quick assembly and disassembly of hoses, spray guns, and lances, reducing setup time and increasing productivity. It features a 1/4" NPTM thread, 0.47" diameter, and 1/4" nominal width (NW), ensuring compatibility with standard pressure washing components. Rated for up to 5000 PSI with a wrench size (SW) of 0.87", it delivers leak-proof performance for industrial and commercial use.

Applications

• High-pressure washer hose and gun connections

• Commercial and industrial cleaning equipment

• Quick-connect systems for spray wands and lances

• Car wash and surface cleaning operations

Key Features

• Made from 100% stainless steel for corrosion resistance and strength

• 1/4" NPTM thread, 0.47" diameter, and 1/4" nominal width (NW)

• Wrench Size (SW): 0.87"

• Rated for up to 5000 PSI

• Enables fast, secure, and leak-free connections

• Ideal for quick tool changes in pressure washing systems

Specs

Material Type: Stainless Steel

Pressure: 5000psi

Thread: 1/4" NPTM

Nominal Width (NW): 1/4"

Wrench Size (SW): 0.87"

Diameter: 0.47"

Weight - 2.80 lbs

Top Rubber Cone

The Mosmatic Seal Kit (External Ring + O-Ring) - 64.501 is a replacement seal kit designed to ensure a secure, leak-proof connection in high-pressure equipment. It includes both an external ring and O-ring, making it ideal for maintaining optimal sealing performance in Mosmatic pressure cleaning systems. This kit is essential for keeping your system running smoothly and preventing leaks, extending the lifespan of your equipment.

The Mosmatic 26.981 lance is a 30-inch high-pressure cleaning wand featuring a bent grip and dual-threaded outlet. Built from high-quality stainless steel, it’s engineered for durability and ease of use in demanding wash bay and industrial environments. This model is part of the LAN-C series and features precision threading and modular construction for a wide range of cleaning applications.

Designed with an 8" bent handle, the lance provides improved ergonomics and control when cleaning hard-to-reach surfaces or working in angled positions. It comes fully assembled and ready for installation, offering compatibility with various fittings and nozzles.

This model includes a 1/4" NPT male inlet and a G3/8" male + 1/8" NPTF outlet combination, making it ideal for systems that require adaptability and long-term performance.

Applications:

• Commercial car wash bays

• Agriculture and equipment cleaning

• Industrial washdown systems

• Pressure washing in service stations

Features:

• Bent 8" grip for better control in angled positions

• 30" total lance length for versatile cleaning

• Dual-threaded outlet: G3/8" M + 1/8" NPTF

• Premium stainless steel construction

• Ready to install and built for 4000 PSI

Specs:

Product Type: Lance
Category: HP Wands
Brand: Mosmatic
Part Number: 26.981
Material: Stainless Steel
Nominal: 1/4"
Pressure: 4000 PSI
Temperature: 250°F max
Threading In: 1/4" NPTM
Threading Out: G3/8" M + 1/8" NPTF
Weight: 1.1 lbs

The Mosmatic 70.028 High-Pressure Quick Connect Plug is engineered for fast, secure, and leak-proof connections in high-pressure cleaning systems. Made from 100% stainless steel, this male-threaded plug offers excellent strength, durability, and corrosion resistance in demanding environments.

Featuring a 3/8" NPTM thread, 0.6" diameter, and 3/8" nominal width (NW), it enables efficient assembly and disassembly of hoses, guns, and wands. With a wrench size (SW) of 0.87" and a maximum pressure rating of 5000 PSI, this plug ensures reliable performance in industrial and commercial applications.

Applications

• Quick-connect systems for pressure washer guns and hoses

• Commercial and industrial cleaning operations

• Surface cleaners, lances, and foam equipment

• Vehicle wash and maintenance tools

Key Features

• Stainless steel construction for long-lasting durability

• 3/8" NPTM thread, 0.6" diameter, and 3/8" nominal width (NW)

• Wrench Size (SW): 0.87"

• Rated up to 5000 PSI

• Provides quick, tight, and leak-free connections

• Ideal for fast equipment changes in pressure systems

Specs

Material Type: Stainless Steel

Pressure: 5000psi

Thread: 3/8" NPTM

Nominal Width (NW): 3/8"

Wrench Size (SW): 0.87"

Diameter: 0.6"

Weight - 2.10oz

The Mosmatic 70.026 High-Pressure Quick Connect Plug delivers reliable and secure connections for high-performance cleaning systems. Built from high-quality stainless steel, it offers excellent corrosion resistance and durability, making it ideal for commercial and industrial applications.

Featuring a 1/4" NPTM thread, 0.47" diameter, and 1/4" nominal width (NW), this plug supports fast and hassle-free assembly or disassembly of hoses, guns, and wands. Its compact design with a wrench size (SW) of 0.67" and pressure rating of 5000 PSI ensures a tight, leak-free fit under high-pressure conditions.

Applications

• Pressure washer hose and spray gun connections

• Industrial and commercial cleaning systems

• Car wash equipment and foam lances

• Quick-connect tools for maintenance operations

Key Features

• Made from 100% stainless steel for durability and corrosion protection

• 1/4" NPTM thread, 0.47" diameter, 1/4" nominal width (NW)

• Wrench Size (SW): 0.67"

• Rated for up to 5000 PSI

• Ensures tight, fast, and secure connections

• Ideal for quick-change setups in pressure washing systems

Specs

Material Type: Stainless Steel

Pressure: 5000psi

Thread: 1/4" NPTM

Nominal Width (NW): 1/4"

Wrench Size (SW): 0.67"

Diameter: 0.47"

Weight: 1oz

The Mosmatic Allrounder Surface Cleaner FL-AER 300 is a compact, high-performance cleaning tool built for precision work in tight or hard-to-reach areas. Designed for both indoor and outdoor applications, this lightweight unit offers professional cleaning power with a built-in recovery system that allows you to reclaim, recycle, or discharge wastewater using a vacuum system.

Equipped with Mosmatic’s proven toggle swivel joint for angled and vertical surface cleaning, the FL-AER 300 ensures fatigue-free operation. Its high-rpm KDYF swivel, precision-balanced rotor arms, and premium stainless steel construction make it exceptionally durable and efficient. With a 12" cleaning path and a pressure capacity of up to 4000 PSI, it delivers professional-grade results in a compact form.

Applications

• Precision cleaning in tight or confined areas

• Vertical surface cleaning such as walls and risers

• Commercial restrooms, kitchens, and food prep areas

• Stairs, curbs, and detailed concrete surfaces

• Light-duty exterior and landscape cleaning

Features

• Integrated fluid recovery system with dual-wall housing for optimized vacuum power

• Toggle swivel joint allows vertical and angled surface cleaning with adjustable movement

• KDYF high-rpm stainless steel swivel with self-lubricated ball bearings

• Dual spring-based carbide seal system for long-term, leak-free operation

• Two 1/8" NPTF rotor arms, precision-welded and balanced, rated up to 4000 PSI

• Includes 2 HP nozzles, 1 HP gun, and three 2 1/4" stainless steel casters

• 12" cleaning diameter for controlled, efficient surface coverage

• Rated up to 4000 PSI and 250°F for high-pressure, high-temperature cleaning tasks

Video

Included

Swivel: 1 x KDYF - Part No: 58.908

Rotor Arm: 2 x 1/8" NPTF - 2w3 Rotor Arm 10" - Part No: 82.623

HP Nozzles: 2 x HP Nozzle 1/8" - Part No: 1503

HP Gun: 1 x HP Gun - Part No: 29.081

Caster: 3 x Stainless Steel Caster 2 1/4" Ø - Part No: 80.943

Specs

Pressure: 4000 psi

Temperature: 250°F

Thread In: 3/8" NPTF

Thread Out (for nozzles): 1/8" NPTF

Diameter: 12"

Weight: 12.3lbs

The Mosmatic 51.129 VER Fitting is a hybrid stainless steel adapter designed to connect 3/8" NPTF (female) threads to G1/4" BSPP male fittings in high-pressure cleaning and industrial systems. With a pressure rating of 7300 PSI, this fitting provides a secure, leak-free transition between tapered (NPTF) and parallel (BSPP) thread types.

Built with corrosion-resistant stainless steel, the 51.129 ensures long-lasting durability and high performance, especially in systems that integrate American and European components.

Applications:

• Pressure washer and car wash systems

• Industrial and commercial cleaning setups

• Converting BSPP tools to NPT hoses

• Hybrid fluid systems with mixed thread standards

Features:

• Threading: 3/8” NPTF (female) x G1/4”M (BSPP)

• Max pressure: 7300 PSI

• Stainless steel for excellent corrosion resistance

• Compatible with BSPP accessories and NPTF lines

• Swiss-made precision by Mosmatic

Specs:

• Body Material Type: Stainless Steel

• Pressure: 7300 PSI

• Threading In: Female 3/8" NPTF

• Threading Out: Male G1/4" BSPP

Specifications:

DKR+DDK ø55/50x30 brass

If you have broken the pipes on your Mosmatic 6" fixed pipe duct cleaner this is the replacement part.

This is NOT the full Duct Cleaner, just the replacement head.

Mosmatic Manifold arm SS TRA-2f 12" Diameter G3/8"F 2x1/8"NPT-F (Duct Spinner Replacement Head) 900.572
