The Mosmatic 50.132 QVS Quick Connection is a premium-grade fitting engineered for use with high-pressure cleaners, hose reels, and quick coupling systems. Crafted from brass, nickel-plated components, and durable plastic, it delivers a lightweight, compact, and solid design ideal for high-performance and space-constrained applications.
This model features a G1 (QV) M22 x 1.5 F inlet thread, a nominal width of 7/32", an overall diameter of 0.33", and a length of 2.34". It comes with an NBR O-ring seal system (with optional EPDM or FKM versions) to ensure leak-free performance. With a 3600 PSI pressure rating, 30 RPM max speed, and 250°F temperature tolerance, it provides the precision and reliability needed in professional cleaning environments.
Applications
-
High-pressure washers and hose reel systems
-
Industrial and commercial quick connect setups
-
Compact pressure washer installations
-
Professional cleaning tools requiring precision and durability
Key Features
-
Brass, nickel-plated, and plastic construction for strength and corrosion resistance
-
Thread Inlet: G1 (QV), M22 x 1.5 F
-
Nominal Width: 7/32"
-
Overall Diameter: 0.33" | Overall Length: 2.34"
-
Includes NBR O-ring seal (EPDM/FKM options available)
-
Rated for 3600 PSI, 30 RPM, and 250°F max temperature
-
Lightweight, compact design for easy installation
-
Built for precision performance in demanding conditions
Specs
Pressure: 3600 psi (27.5 MPa) also avaliable as 7300 psi
Temperature: 250°F
RPM: max 30 rpm
Material Type: Brass, Nickel plated, Plastic
Inner Part: Stainless steel
Seal: O-ring NBR (optional: EPDM or FKM)
Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)
Thread In: G1 (QV) M22x1.5 F
S1: 5/16"
Nominal Width (NW): 7/32”
Length 1 (L1) (overall length) : 2.34"
Diameter 1 (D1): 0.33"
Diameter 2 (D2): 0.35"
Diameter 3 (D3): 0.45"
Color: Blue
Weight: 2.50 oz
The Mosmatic 50.133 QVS Quick Connection is a precision-engineered fitting built for high-pressure cleaners, hose reels, and quick coupling systems. Designed using brass, nickel-plated components, and durable plastic, this connection combines a compact, lightweight form with long-lasting performance under demanding conditions.
It features a G1 (QV) M22 x 1.5 F inlet thread, a nominal width of 1/4", an overall diameter of 0.39", and a length of 2.40". Equipped with a standard NBR O-ring seal system (also available in EPDM or FKM options), it ensures excellent sealing and leak prevention. Rated for 3600 PSI, with a maximum RPM of 30 and temperature capacity up to 250°F, this quick connect delivers top-tier efficiency and durability for professional applications.
Applications
-
High-pressure washer systems
-
Hose reel and quick coupling configurations
-
Commercial and industrial pressure cleaning setups
-
Compact installations requiring durable, precise connections
Key Features
-
Made from brass, nickel-plated components, and plastic
-
Thread Inlet: G1 (QV), M22 x 1.5 F
-
Nominal Width: 1/4"
-
Overall Diameter: 0.39" | Overall Length: 2.40"
-
Includes NBR O-ring seal system (EPDM/FKM optional)
-
Rated for 3600 PSI, 30 RPM, and 250°F max temperature
-
Compact, lightweight, and easy to install
-
Ideal for precise, secure, high-pressure connections
Specs
Pressure: 3600 psi (27.5 MPa) also avaliable as 7300 psi
Temperature: 250°F
RPM: max 30 rpm
Material Type: Brass, Nickel plated, Plastic
Inner Part: Stainless steel
Seal: O-ring NBR (optional: EPDM or FKM)
Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)
Thread IN: G1 (QV) M22x1.5 F
S1: 3/8"
Nominal Width (NW): 1/4”
Length 1 (L1) (overall length) : 2.40"
Diameter 1 (D1): 0.39"
Diameter 2 (D2): 0.42"
Diameter 3 (D3): 0.53"
Color: Blue
Weight: 2.10 oz
The Mosmatic DGK Swivel 32.051 is a compact, high-quality swivel designed for high-pressure hose connections, HP-guns, and hydraulic applications where live rotation is essential. Engineered with a nickel-plated brass and stainless steel body, this swivel is built to withstand corrosion and daily use in professional environments.
This model features a 1x thrust ball bearing and a durable O-ring NBR seal system (optional EPDM or FKM), allowing smooth, low-torque rotation under maximum pressure. Its maintenance-free design ensures dependable performance in compact spaces, ideal for reducing hose kinks and improving maneuverability in pressurized systems.
Applications
-
High-pressure spray guns
-
Hose and hydraulic connections
-
Ceiling booms and rotating booms
-
Tangle-free hose management
-
Pressure washing and industrial cleaning
Key Features
-
Model: Mosmatic DGK 32.051
-
Material: Brass, nickel-plated with stainless steel components
-
Thread IN: 1/4” NPTM
-
Thread OUT: 1/4” NPTM
-
Seal Type: O-ring NBR (optional EPDM or FKM)
-
Bearings: 1x thrust ball bearing
-
Design: Compact, corrosion-resistant, low-torque
-
Live Rotation: At full operating pressure
-
Overall Length: 2.05"
-
Nominal Width (NW): 1/4”
-
Wrench Size (SW): 0.94”
-
Max Pressure: 4000 PSI
-
Max RPM: 30
-
Max Temperature: 250°F
Specs
Pressure: 4000 psi (27.5 MPa)
Temperature: 250°F
RPM: max 30 rpm
Material Type: Stainless steel, Brass, Nickel plated
Inner Part: Stainless steel
Seal: O-ring NBR (optional: EPDM or FKM)
Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)
Thread In: G1 1/4" NPTM
Thread In: G1 1/4" NPTM
Nominal Width (NW): 1/4”
Wrench Size 1 (SW1): 0.94"
Wrench Size 2 (SW2): 0.67"
Length 1 (L1) (overall length) : 2.05"
Lenght 2 (L2): 0.39"
Lenght 3 (L3): 0.43"
Weight: 3.5 oz
The Mosmatic DGK Swivel 32.053 is a high-performance swivel designed for tangle-free hose connections, high-pressure spray guns, and hydraulic applications. Built from nickel-plated brass and stainless steel, it offers exceptional durability and corrosion resistance in compact and demanding environments.
This swivel includes 1x thrust ball bearing and an O-ring NBR seal system (optional EPDM or FKM), delivering smooth, low-torque rotation under full pressure. With a maintenance-free design, it's ideal for use in high-pressure cleaning systems, industrial hydraulics, and hose management setups requiring reliable swivel action.
Applications
-
High-pressure spray guns and cleaning equipment
-
Hydraulic systems
-
Hose and boom connections
-
Tangle-free hose operation
-
Industrial wash bays and automotive shops
Key Features
-
Model: Mosmatic DGK 32.053
-
Material: Nickel-plated brass with stainless steel components
-
Thread IN: 1/4” NPTM
-
Thread OUT: 3/8” NPTM
-
Seal Type: O-ring NBR (optional EPDM or FKM)
-
Bearings: 1x thrust ball bearing
-
Design: Compact, corrosion-resistant, low-torque
-
Live Rotation: At full operating pressure
-
Overall Length: 2.09"
-
Nominal Width (NW): 1/4”
-
Wrench Size (SW): 0.94”
-
Max Pressure: 4000 PSI
-
Max RPM: 30
-
Max Temperature: 250°F
Specs
Pressure: 4000 psi (27.5 MPa)
Temperature: 250°F
RPM: max 30 rpm
Material Type: Stainless steel, Brass, Nickel plated
Inner Part: Stainless steel
Seal: O-ring NBR (optional: EPDM or FKM)
Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)
Thread In: G1 1/4" NPTM
Thread In: G1 3/8" NPTM
Nominal Width (NW): 1/4”
Wrench Size 1 (SW1): 0.94"
Wrench Size 2 (SW2): 0.75"
Length 1 (L1) (overall length) : 2.09"
Lenght 2 (L2): 0.39"
Lenght 3 (L3): 0.39"
Weight: 3.9 oz
The Mosmatic DGK Swivel 32.081 is a high-performance nickel-plated brass and stainless steel swivel engineered for hose connections, HP guns, hydraulics, and tangle-free operations. Its compact design offers live rotation at full pressure, reducing torque and enhancing maneuverability in demanding cleaning and industrial environments.
Designed for durability and minimal maintenance, the swivel features a stainless steel thrust ball bearing and a reliable O-ring NBR seal system, with optional upgrades to EPDM or FKM. Perfect for high and low-pressure applications, the DGK 32.081 ensures smooth, low-resistance rotation for optimal performance.
Applications
-
High-pressure spray guns
-
Hydraulic and pneumatic hose assemblies
-
Ceiling booms and hose reels
-
Compact cleaning tools
-
Tangle-free hose management
Key Features
-
Model: Mosmatic DGK 32.081
-
Material: Nickel-plated brass and stainless steel
-
Thread IN (G1): 1/4” NPTM
-
Seal System: O-ring NBR (optional EPDM or FKM)
-
Bearing Type: 1x thrust ball bearing
-
Compact & Lightweight: Ideal for space-limited tools
-
Maintenance-Free: Sealed, long-lasting performance
-
Live Rotation: Smooth, low-torque operation at high pressure
-
Diameter: 0.27”
-
Overall Length: 2.55”
-
Nominal Width (NW): 1/8”
-
Wrench Size (SW): 0.94”
-
Max Pressure: 4000 PSI
-
Max RPM: 30
-
Max Temperature: 250°F
Specs
Pressure: 4000 psi (27.5 MPa)
Temperature: 250°F
RPM: max 30 rpm
Material Type: Stainless steel, Brass, Nickel plated
Inner Part: Stainless steel
Seal: O-ring NBR (optional: EPDM or FKM)
Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)
Thread In: G1 1/4" NPTM
S1: 1/4"
Nominal Width (NW): 1/8”
Wrench Size 1 (SW1): 0.94"
Length 1 (L1) (overall length) : 2.55"
Lenght 2 (L2): 0.39"
Diameter 1 (D1): 0.27"
Diameter 2 (D2): 0.29"
Diameter 3 (D3): 0.37"
Weight: 2.8 oz
The Mosmatic DGK Swivel 32.082 is a compact and durable nickel-plated brass and stainless steel swivel engineered for high-pressure guns, hydraulic systems, hose connections, and tangle-free applications. Designed for smooth rotation under pressure, this swivel delivers maintenance-free performance and exceptional durability.
Built with a thrust ball bearing and a robust O-ring NBR seal system (with optional EPDM or FKM), the DGK 32.082 enables live rotation even at maximum pressure, offering exceptional maneuverability for demanding cleaning and industrial environments.
Applications
-
High-pressure guns and lances
-
Hydraulic hose connections
-
Ceiling booms and hose reels
-
Tangle-free hose systems
-
Compact industrial machinery
Key Features
-
Model: Mosmatic DGK 32.082
-
Material: Nickel-plated brass and stainless steel
-
Thread IN (G1): 1/4” NPTM
-
Seal System: O-ring NBR (optional EPDM or FKM)
-
Bearing: 1x thrust ball bearing
-
Low Torque: Smooth rotation under pressure
-
Maintenance-Free: Sealed system, long service life
-
Diameter: 0.33”
-
Overall Length: 2.63”
-
Nominal Width (NW): 7/32”
-
Wrench Size (SW): 0.94”
-
Max Pressure: 4000 PSI
-
Max RPM: 30
-
Max Temperature: 250°F
Specs
Pressure: 4000 psi (27.5 MPa)
Temperature: 250°F
RPM: max 30 rpm
Material Type: Stainless steel, Brass, Nickel plated
Inner Part: Stainless steel
Seal: O-ring NBR (optional: EPDM or FKM)
Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)
Thread In: G1 1/4" NPTM
S1: 5/16"
Nominal Width (NW): 7/32”
Wrench Size 1 (SW1): 0.94"
Length 1 (L1) (overall length) : 2.63"
Lenght 2 (L2): 0.39"
Diameter 1 (D1): 0.33"
Diameter 2 (D2): 0.34"
Diameter 3 (D3): 0.44"
Weight: 2.8 oz
The Mosmatic DGK Swivel 32.089 is a compact, high-performance brass and stainless steel swivel designed for high and low-pressure cleaning, hose connections, hydraulic setups, and tangle-free hose applications. Engineered with live rotation under maximum pressure, this swivel offers superior functionality and a long-lasting, maintenance-free design.
The unit features a thrust ball bearing for smooth operation and an O-ring NBR seal system, with optional EPDM or FKM materials for enhanced chemical resistance. Its nickel-plated finish ensures durability and corrosion resistance in demanding environments.
Applications
-
High-pressure guns and lances
-
Hydraulic and pneumatic hose connections
-
Hose reels and ceiling booms
-
Industrial cleaning systems
-
Tangle-free hose management
Key Features
-
Model: Mosmatic DGK 32.089
-
Material: Nickel-plated brass and stainless steel
-
Thread IN (G1): 1/4” NPTM
-
Seal System: O-ring NBR (optional EPDM or FKM)
-
Bearing: 1x thrust ball bearing
-
Rotation: Live under maximum pressure
-
Maintenance-Free: Sealed stainless steel bearing
-
Overall Diameter: 0.40”
-
Overall Length: 2.70”
-
Nominal Width (NW): 1/4”
-
Wrench Size (SW): 0.94”
-
Max Pressure: 4000 PSI
-
Max RPM: 30
-
Max Temperature: 250°F
Specs
Pressure: 4000 psi (27.5 MPa)
Temperature: 250°F
RPM: max 30 rpm
Material Type: Stainless steel, Brass, Nickel plated
Inner Part: Stainless steel
Seal: O-ring NBR (optional: EPDM or FKM)
Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)
Thread In: G1 1/4" NPTM
S1: 3/8"
Nominal Width (NW): 1/4”
Wrench Size 1 (SW1): 0.94"
Length 1 (L1) (overall length) : 2.70"
Lenght 2 (L2): 0.39"
Diameter 1 (D1): 0.40"
Diameter 2 (D2): 0.42"
Diameter 3 (D3): 0.54"
Weight: 2.6 oz
The Mosmatic DGK Swivel 32.153 is a compact, high-performance swivel engineered for high-pressure spray guns, hose connections, hydraulic systems, and tangle-free hose applications. Constructed from nickel-plated brass with stainless steel components, it delivers excellent corrosion resistance and long-term durability.
Equipped with a thrust ball bearing and O-ring NBR seal system (optional EPDM or FKM), this swivel enables live rotation at maximum pressure with very low torque. The maintenance-free design ensures reliability and smooth performance in even the most demanding settings.
Applications
-
High-pressure spray guns
-
Hose connection systems
-
Hydraulic line installations
-
Ceiling booms and wash bays
-
Industrial and automotive cleaning setups
Key Features
-
Model: Mosmatic DGK 32.153
-
Material: Nickel-plated brass and stainless steel
-
Thread IN: 3/8” NPTM
-
Thread OUT: 3/8” NPTM
-
Seal System: O-ring NBR (optional EPDM or FKM)
-
Bearings: 1x thrust ball bearing
-
Design: Compact, corrosion-resistant, low-torque rotation
-
Live Rotation: At full operating pressure
-
Overall Length: 2.13"
-
Nominal Width (NW): 1/4”
-
Wrench Size (SW): 0.94”
-
Max Pressure: 4000 PSI
-
Max RPM: 30
-
Max Temperature: 250°F
Specs
Pressure: 4000 psi (27.5 MPa)
Temperature: 250°F
RPM: max 30 rpm
Material Type: Stainless steel, Brass, Nickel plated
Inner Part: Stainless steel
Seal: O-ring NBR (optional: EPDM or FKM)
Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)
Thread In: G1 3/8" NPTM
Thread In: G1 3/8" NPTM
Nominal Width (NW): 1/4”
Wrench Size 1 (SW1): 0.94"
Wrench Size 2 (SW2): 0.75"
Length 1 (L1) (overall length) : 2.13"
Lenght 2 (L2): 0.43"
Lenght 3 (L3): 0.47"
Weight: 4.2 oz
The Mosmatic DGK Swivel 32.181 is a durable and compact stainless steel/brass swivel engineered for high-performance applications in high-pressure guns, hydraulic systems, and hose connections. This nickel-plated swivel allows live rotation at maximum pressure, making it perfect for tangle-free and efficient hose management.
With a robust thrust ball bearing and an O-ring NBR seal system (with optional EPDM or FKM), this swivel is built for reliability and longevity in both industrial and commercial environments. Its maintenance-free design ensures smooth operation under demanding conditions.
Applications
-
High-pressure spray guns
-
Hydraulic and pneumatic hose connections
-
Hose reels and ceiling booms
-
Tangle-free hose setups
-
Industrial cleaning and washdown systems
Key Features
-
Model: Mosmatic DGK 32.181
-
Material: Nickel-plated brass and stainless steel
-
Thread IN (G1): 3/8” NPTM
-
Seal System: O-ring NBR (optional EPDM or FKM)
-
Bearing: 1x thrust ball bearing
-
Design: Compact, maintenance-free
-
Live Rotation: Operates at max pressure
-
Overall Diameter: 0.27”
-
Overall Length: 2.59”
-
Nominal Width (NW): 1/8”
-
Wrench Size (SW): 0.94”
-
Max Pressure: 4000 PSI
-
Max RPM: 30
-
Max Temperature: 250°F
Specs
Pressure: 4000 psi (27.5 MPa)
Temperature: 250°F
RPM: max 30 rpm
Material Type: Stainless steel, Brass, Nickel plated
Inner Part: Stainless steel
Seal: O-ring NBR (optional: EPDM or FKM)
Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)
Thread In: G1 3/8" NPTM
S1: 1/4"
Nominal Width (NW): 1/8”
Wrench Size 1 (SW1): 0.94"
Length 1 (L1) (overall length) : 2.59"
Lenght 2 (L2): 0.43"
Diameter 1 (D1): 0.27"
Diameter 2 (D2): 0.29"
Diameter 3 (D3): 0.37"
Weight: 3.2 oz
The Mosmatic DGK Swivel 32.182 is a premium-quality swivel made of nickel-plated brass and stainless steel, designed for high-efficiency use in high-pressure guns, hydraulic connections, and hose systems. With a compact design and live rotation under full pressure, this swivel enables tangle-free operation and optimal performance in demanding environments.
Featuring a thrust ball bearing and an O-ring NBR seal system (with optional EPDM or FKM), it ensures smooth operation with very low torque, even at high pressures. Its sealed stainless steel bearings offer long-lasting durability with no maintenance required.
Applications
-
High-pressure cleaning guns
-
Hydraulic and pneumatic hose systems
-
Ceiling booms and hose reels
-
Tangle-free hose setups
-
Industrial and commercial cleaning systems
Key Features
-
Model: Mosmatic DGK 32.182
-
Material: Nickel-plated brass and stainless steel
-
Thread IN (G1): 3/8” NPTM
-
Seal System: O-ring NBR (optional EPDM or FKM)
-
Bearing: 1x thrust ball bearing
-
Design: Maintenance-free, compact size
-
Rotation: Live rotation under max pressure
-
Overall Diameter: 0.33”
-
Overall Length: 2.68”
-
Nominal Width (NW): 7/32”
-
Wrench Size (SW): 0.94”
-
Max Pressure: 4000 PSI
-
Max RPM: 30
-
Max Temperature: 250°F
Specs
Pressure: 4000 psi (27.5 MPa)
Temperature: 250°F
RPM: max 30 rpm
Material Type: Stainless steel, Brass, Nickel plated
Inner Part: Stainless steel
Seal: O-ring NBR (optional: EPDM or FKM)
Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)
Thread In: G1 3/8" NPTM
S1: 5/16"
Nominal Width (NW): 7/32”
Wrench Size 1 (SW1): 0.94"
Length 1 (L1) (overall length) : 2.68"
Lenght 2 (L2): 0.43"
Diameter 1 (D1): 0.33"
Diameter 2 (D2): 0.34"
Diameter 3 (D3): 0.44"
Weight: 3.3 oz
The Mosmatic DGK Swivel 32.189 is a robust and compact swivel crafted from nickel-plated brass and stainless steel, engineered for smooth and tangle-free operation in high-pressure gun and hydraulic hose systems. This high-performance swivel delivers live rotation under maximum pressure and is maintenance-free, making it perfect for both industrial and commercial applications.
Equipped with a thrust ball bearing and O-ring NBR seal system (upgradeable to EPDM or FKM), this swivel is designed for very low torque operation, providing consistent, easy rotation even at full pressure.
Applications
-
High-pressure cleaning guns
-
Hose and hydraulic line connections
-
Ceiling booms and hose reels
-
Tangle-free hose assemblies
-
Industrial washdown systems
Key Features
-
Model: Mosmatic DGK 32.189
-
Material: Stainless steel and nickel-plated brass
-
Thread IN (G1): 3/8” NPTM
-
Seal Type: O-ring NBR (optional EPDM or FKM)
-
Bearing: 1x thrust ball bearing
-
Rotation: Live rotation under full pressure
-
Design: Compact, corrosion-resistant, maintenance-free
-
Overall Diameter: 0.40”
-
Overall Length: 2.76”
-
Nominal Width (NW): 1/4”
-
Wrench Size (SW): 0.94”
-
Max Pressure: 4000 PSI
-
Max RPM: 30
-
Max Temperature: 250°F
Specs
Pressure: 4000 psi (27.5 MPa)
Temperature: 250°F
RPM: max 30 rpm
Material Type: Stainless steel, Brass, Nickel plated
Inner Part: Stainless steel
Seal: O-ring NBR (optional: EPDM or FKM)
Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)
Thread In: G1 3/8" NPTM
S1: 3/8"
Nominal Width (NW): 1/4”
Wrench Size 1 (SW1): 0.94"
Length 1 (L1) (overall length) : 2.76"
Lenght 2 (L2): 0.43"
Diameter 1 (D1): 0.40"
Diameter 2 (D2): 0.42"
Diameter 3 (D3): 0.54"
Weight: 4.8 oz
Showing 30/141
