The Mosmatic DGE Swivel - 34.753 is a precision-engineered stainless steel swivel built for high-pressure, high-flow applications in demanding environments. Designed to manage thrust and radial forces, this swivel features 1x thrust ball bearing and 2x sliding bearings for long-lasting, stable performance. Ideal for pharmaceutical, food processing, industrial cleaning, and automatic car wash systems, it offers a corrosion-resistant design, a 5000 PSI pressure rating, and heat resistance up to 250°F.

Applications:

• Pharmaceutical manufacturing and clean-in-place systems

• Food and beverage processing and sanitation lines

• Automatic car wash sprayers and rinsing systems

• Industrial washdown and fluid transfer systems

Key Features:

• Durable stainless steel body for corrosion resistance

• With 1x thrust ball bearing and 2 x sliding bearings

• High-flow design supports efficient liquid transfer

• Withstands both thrust and radial loads

• Thread IN: 1/2" NPTF | Thread OUT: 1/2" NPTM

• Nominal Width (NW): 1/2"

• Diameter: 1.65"

• Overall Length: 2.17"

• Max Pressure: 5000 PSI

• Max RPM: 30

• Max Operating Temperature: 250°F

Specs

Pressure: 5000 psi

Temperature: 250°F

RPM: Max. 30

Material Type: Stainless Steel

Inner Part: Stainless Steel

Seal: O-ring NBR

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 1/2"NPTF

Thread Out: G2 1/2"NPTM

Nominal Width (NW): 1/2"

Wrench Size 1 (SW1): 0.87

Wrench Size 2 (SW2): 1.38

Diameter (D1): 1.65

Length 1 (L1) (overall length): 2.17"

Length 2 (L2): 2.17

Length 3 (L3): 0.59

Weight: 18.9oz

The Mosmatic DGE Swivel - 34.765 is a rugged, high-flow stainless steel swivel designed for high-pressure applications where thrust and radial forces must be managed reliably. Equipped with 1x thrust ball bearing and 2x sliding bearings, this swivel delivers stable, low-RPM rotation and long-term durability. Its corrosion-resistant stainless steel construction makes it ideal for demanding environments such as pharmaceutical processing, food and beverage sanitation, automatic car wash systems, and industrial fluid handling.

Applications:

• Food and beverage cleaning and transfer systems

• Pharmaceutical production and CIP processes

• Rotary spray arms in car wash systems

• Industrial chemical handling and washdown

Key Features:

• Corrosion-resistant stainless steel housing

• With 1x thrust ball bearing and 2 x sliding bearings

• Handles both thrust and radial loads under high pressure

• High-flow design with smooth low-RPM operation

• Thread IN: 1" NPTF | Thread OUT: 1" NPTF

• Nominal Width (NW): 1"

• Diameter: 2.35"

• Overall Length: 3.54"

• Max Pressure: 2900 PSI

• Max RPM: 30

• Max Operating Temperature: 250°F

Specs

Pressure: 2900 psi

Temperature: 250°F

RPM: Max. 30

Material Type: Stainless Steel

Inner Part: Stainless Steel

Seal: O-ring NBR

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 1"NPTF

Thread Out: G2 1"NPTF

Nominal Width (NW): 1"

Wrench Size 1 (SW1): 1.42

Wrench Size 2 (SW2): 1.97

Diameter (D1): 2.35"

Length 1 (L1) (overall length): 3.54"

Length 2 (L2): 2.56

Weight: 44oz

The Mosmatic DGE Swivel - 34.755 is a precision-engineered stainless steel swivel built for high-pressure and high-flow applications. Designed to handle both thrust and radial forces, this swivel features 1x thrust ball bearing and 2x sliding bearings, delivering smooth, reliable rotation even in demanding conditions. Corrosion-resistant and rated for 2900 PSI, this swivel is ideal for use in pharmaceutical, food service, automatic car wash, and industrial fluid systems where hygiene, performance, and durability are essential.

Applications:

• Food and beverage sanitation systems

• Pharmaceutical processing and CIP systems

• Industrial washdown and high-pressure cleaning

• Automatic car wash rotary spray systems

Key Features:

• Heavy-duty stainless steel construction for superior corrosion resistance

• With 1x thrust ball bearing and 2 x sliding bearings

• Handles both thrust and radial forces in low-RPM environments

• High-flow capability with consistent performance

• Thread IN: 1" NPTF | Thread OUT: 1" NPTM

• Nominal Width (NW): 1"

• Diameter: 2.35"

• Overall Length: 3.74"

• Max Pressure: 2900 PSI

• Max RPM: 30

• Max Operating Temperature: 250°F

Specs

Pressure: 2900 psi

Temperature: 250°F

RPM: Max. 30

Material Type: Stainless Steel

Inner Part: Stainless Steel

Seal: O-ring NBR

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 1"NPTF

Thread Out: G2 1"NPTM

Nominal Width (NW): 1"

Wrench Size 1 (SW1): 1.42

Wrench Size 2 (SW2): 1.97

Diameter (D1): 2.35"

Length 1 (L1) (overall length): 3.74"

Length 2 (L2): 2.56

Length 3 (L3): 0.71

Weight: 40.3oz

The Mosmatic DGE Swivel - 34.754 is a high-performance stainless steel swivel engineered for high-pressure, high-flow operations across a variety of demanding environments. Designed to support both thrust and radial forces, this swivel features 1x thrust ball bearing and 2x sliding bearings for smooth, reliable operation. With a pressure rating of 5000 PSI and temperature resistance up to 250°F, it’s perfect for applications in pharmaceutical manufacturing, food processing, industrial cleaning, and automatic car wash systems.

Applications:

• Pharmaceutical fluid handling and CIP systems

• Food and beverage sanitation and spray lines

• Car wash sprayers and rotary connections

• Industrial washdown and chemical systems

Key Features:

• Rugged stainless steel construction for corrosion resistance

• With 1x thrust ball bearing and 2 x sliding bearings

• High-flow capacity for demanding applications

• Supports both radial and thrust forces at low RPM

• Thread IN: 3/4" NPTF | Thread OUT: 3/4" NPTM

• Nominal Width (NW): 3/4"

• Diameter: 1.97"

• Overall Length: 3.66"

• Max Pressure: 5000 PSI

• Max RPM: 30

• Max Operating Temperature: 250°F

Specs

Pressure: 5000 psi

Temperature: 250°F

RPM: Max. 30

Material Type: Stainless Steel

Inner Part: Stainless Steel

Seal: O-ring NBR

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 3/4"NPTF

Thread Out: G2 3/4"NPTM

Nominal Width (NW): 3/4"

Wrench Size 1 (SW1): 1.06

Wrench Size 2 (SW2): 1.58

Diameter (D1): 1.97"

Length 1 (L1) (overall length): 3.66"

Length 2 (L2): 2.58

Length 3 (L3): 0.63

Weight: 27.8oz

The Mosmatic DGE Swivel - 34.787 is a robust stainless steel swivel engineered for high-pressure and high-flow systems that must reliably manage thrust and radial forces. Designed with a durable bearing system—featuring 1x thrust ball bearing and 2x sliding bearings—this swivel ensures smooth, long-lasting performance under continuous use. Rated for 2900 PSI and capable of withstanding temperatures up to 250°F, it is perfect for demanding pharmaceutical, food processing, industrial cleaning, and automatic car wash applications.

Applications:

• Food and beverage production and sanitation lines

• Pharmaceutical clean-in-place (CIP) systems

• Industrial fluid handling and high-pressure washdowns

• Rotary spray arms and booms in automatic car washes

Key Features:

• Corrosion-resistant stainless steel construction

• With 1x thrust ball bearing and 2 x sliding bearings

• Supports both thrust and radial loads with high stability

• High-flow performance designed for low-RPM, high-pressure use

• Thread IN: 1 1/2" NPTF | Thread OUT: 1 1/2" NPTF

• Nominal Width (NW): 1 1/2"

• Diameter: 3.33"

• Overall Length: 5.87"

• Max Pressure: 2900 PSI

• Max RPM: 30

• Max Operating Temperature: 250°F

Specs

Pressure: 2900 psi

Temperature: 250°F

RPM: Max. 30

Material Type: Stainless Steel

Inner Part: Stainless Steel

Seal: O-ring NBR

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 1 1/2"NPTF

Thread Out: G2 1 1/2"NPTF

Nominal Width (NW): 1 1/2"

Wrench Size (SW1): 2.13

Diameter 1 (D1): 3.33"

Diameter 2 (D2): 3.98

Length 1 (L1) (overall length): 5.87"

Length 2 (L2): 3.17

Length 4 (L4): 1.66

Length 5 (L5): 1.42

Weight: 181.5oz

The Mosmatic DGE Swivel - 34.786 is a high-performance stainless steel swivel engineered for high-pressure applications that demand reliable management of thrust and radial forces. Equipped with a reliable bearing system—including 1x thrust ball bearing and 2x sliding bearings—this swivel ensures smooth, consistent operation even in the most demanding conditions. With a pressure rating of 2900 PSI and temperature resistance up to 250°F, it is an ideal choice for pharmaceutical, food processing, industrial cleaning, and automatic car wash systems.

Applications:

• Food and beverage sanitation and processing systems

• Pharmaceutical clean-in-place (CIP) applications

• Industrial washdown and fluid transfer

• Rotary spray systems in automatic car washes

Key Features:

• Durable stainless steel construction for maximum corrosion resistance

• With 1x thrust ball bearing and 2 x sliding bearings

• Supports high-flow, low-RPM, high-pressure applications

• Designed to handle both thrust and radial loads efficiently

• Thread IN: 1 1/4" NPTF | Thread OUT: 1 1/4" NPTF

• Nominal Width (NW): 1 1/4"

• Diameter: 2.76"

• Overall Length: 5.37"

• Max Pressure: 2900 PSI

• Max RPM: 30

• Max Operating Temperature: 250°F

Specs

Pressure: 2900 psi

Temperature: 250°F

RPM: Max. 30

Material Type: Stainless Steel

Inner Part: Stainless Steel

Seal: O-ring NBR

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 1 1/4"NPTF

Thread Out: G2 1 1/4"NPTF

Nominal Width (NW): 1 1/4"

Wrench Size (SW1): 1.97

Diameter 1 (D1): 2.76"

Diameter 2 (D2): 3.07

Length 1 (L1) (overall length): 5.37"

Length 2 (L2): 2.84

Length 4 (L4): 1.18

Length 5 (L5): 1.30

Weight: 94.7oz

The Mosmatic DGE Swivel - 34.785 is a durable stainless steel swivel engineered for high-pressure environments requiring precise management of thrust and radial forces. Featuring a reliable bearing system with 1x thrust ball bearing and 2x sliding bearings, this swivel ensures smooth operation under continuous use. Designed for a max pressure of 2900 PSI and temperature resistance up to 250°F, it is the ideal solution for pharmaceutical, food processing, industrial, and automatic car wash applications.

Applications:

• Food and beverage production and sanitation systems

• Pharmaceutical clean-in-place (CIP) and processing lines

• Industrial washdown and chemical distribution

• Rotary spray arms in automatic car washes

Key Features:

• Heavy-duty stainless steel construction for corrosion resistance

• With 1x thrust ball bearing and 2 x sliding bearings

• Engineered to handle both thrust and radial loads

• High-flow performance designed for low-RPM applications

• Thread IN: 1" NPTF | Thread OUT: 1" NPTF

• Nominal Width (NW): 1"

• Diameter: 2.35"

• Overall Length: 4.65"

• Max Pressure: 2900 PSI

• Max RPM: 30

• Max Operating Temperature: 250°F

Specs

Pressure: 2900 psi

Temperature: 250°F

RPM: Max. 30

Material Type: Stainless Steel

Inner Part: Stainless Steel

Seal: O-ring NBR

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 1"NPTF

Thread Out: G2 1"NPTF

Nominal Width (NW): 1"

Wrench Size (SW1): 1.42

Diameter 1 (D1): 2.35"

Diameter 2 (D2): 2.83

Length 1 (L1) (overall length): 4.65"

Length 2 (L2): 2.52

Length 4 (L4): 1.18

Length 5 (L5): 1.14

Weight: 74.3oz

The Mosmatic DGE Swivel - 34.780 is a robust stainless steel swivel designed for high-pressure applications involving both thrust and radial forces. Built for durability and precision, this swivel features a robust bearing system that includes 1x thrust ball bearing and 2x sliding bearings, ensuring smooth, long-lasting performance. With a pressure rating of 5000 PSI and temperature resistance up to 250°F, it is ideal for continuous operation in pharmaceutical, food service, industrial, and automatic car wash environments.

Applications:

• Food and beverage production and sanitation

• Clean-in-place (CIP) systems in pharmaceutical facilities

• Industrial washdown and chemical processing

• Rotary arms and sprayers in automatic car wash systems

Key Features:

• Heavy-duty stainless steel body for corrosion resistance

• With 1x thrust ball bearing and 2 x sliding bearings

• Designed to support both thrust and radial load applications

• High-flow, low-RPM swivel for continuous-duty use

• Thread IN: 3/4" NPTF | Thread OUT: 3/4" NPTF

• Nominal Width (NW): 3/4"

• Diameter: 1.97"

• Overall Length: 4.35"

• Max Pressure: 5000 PSI

• Max RPM: 30

• Max Operating Temperature: 250°F

Specs

Pressure: 5000 psi

Temperature: 250°F

RPM: Max. 30

Material Type: Stainless Steel

Inner Part: Stainless Steel

Seal: O-ring NBR

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 3/4"NPTF

Thread Out: G2 3/4"NPTF

Nominal Width (NW): 3/4"

Wrench Size (SW1): 1.26

Diameter 1 (D1): 1.97"

Diameter 2 (D2): 1.97

Length 1 (L1) (overall length): 4.35"

Length 2 (L2): 2.40

Length 4 (L4): 0.75

Length 5 (L5): 0.87

Weight: 36.0oz

The Mosmatic DGE Swivel - 34.783 is a high-quality stainless steel swivel designed for high-pressure fluid systems that demand durability and precision. Engineered to handle both thrust and radial forces, this swivel features a robust bearing system with 1x thrust ball bearing and 2x sliding bearings for smooth, long-lasting performance. With a pressure rating of 5000 PSI and a temperature tolerance up to 250°F, it's perfectly suited for continuous operation in pharmaceutical, food service, industrial, and automatic car wash applications.

Applications:

• Pharmaceutical clean-in-place (CIP) systems

• Food and beverage processing and sanitation

• Industrial high-pressure washdown and chemical delivery

• Rotary spray systems in car washes

Key Features:

• Corrosion-resistant stainless steel construction

• With 1x thrust ball bearing and 2 x sliding bearings

• Built to handle both thrust and radial loads

• High-flow, low-RPM design optimized for long service life

• Thread IN: 1/2" NPTF | Thread OUT: 1/2" NPTF

• Nominal Width (NW): 1/2"

• Diameter: 1.65"

• Overall Length: 3.82"

• Max Pressure: 5000 PSI

• Max RPM: 30

• Max Operating Temperature: 250°F

Specs

Pressure: 5000 psi

Temperature: 250°F

RPM: Max. 30

Material Type: Stainless Steel

Inner Part: Stainless Steel

Seal: O-ring NBR

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 1/2"NPTF

Thread Out: G2 1/2"NPTF

Nominal Width (NW): 1/2"

Wrench Size (SW1): 1.06

Diameter 1 (D1): 1.65"

Diameter 2 (D2): 1.65

Length 1 (L1) (overall length): 3.82"

Length 2 (L2): 2.09

Length 4 (L4): 0.63

Length 5 (L5): 0.63

Weight: 22.8oz

The Mosmatic DGE Swivel - 34.782 is a premium stainless steel swivel designed for high-pressure applications where superior handling of thrust and radial forces is critical. Featuring a robust bearing system—with 1x thrust ball bearing and 2x sliding bearings—this swivel ensures smooth, reliable operation even under continuous heavy-duty use. Built to withstand up to 5000 PSI and temperatures reaching 250°F, it’s an ideal choice for pharmaceutical, food service, industrial washdown, and automatic car wash systems.

Applications:

• Food and beverage sanitation and high-pressure fluid systems

• Pharmaceutical processing and clean-in-place (CIP) operations

• Industrial chemical handling and washdown stations

• Rotary connections in automatic car wash equipment

Key Features:

• Corrosion-resistant stainless steel construction for durability

• With 1x thrust ball bearing and 2 x sliding bearings

• Handles both thrust and radial force applications efficiently

• High-flow capacity with low-RPM, high-pressure operation

• Thread IN: 3/8" NPTF | Thread OUT: 3/8" NPTF

• Nominal Width (NW): 3/8"

• Diameter: 1.65"

• Overall Length: 3.39"

• Max Pressure: 5000 PSI

• Max RPM: 30

• Max Operating Temperature: 250°F

Specs

Pressure: 5000 psi

Temperature: 250°F

RPM: Max. 30

Material Type: Stainless Steel

Inner Part: Stainless Steel

Seal: O-ring NBR

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 3/8"NPTF

Thread Out: G2 3/8"NPTF

Nominal Width (NW): 3/8"

Wrench Size (SW1): 0.87

Diameter 1 (D1): 1.65"

Diameter 2 (D2): 1.65

Length 1 (L1) (overall length): 3.39"

Length 2 (L2): 2.09

Length 4 (L4): 0.67

Length 5 (L5): 0.55

Weight: 23.5oz

The Mosmatic DGE Swivel - 34.777 is a heavy-duty stainless steel swivel engineered for high-pressure operations where managing thrust and radial forces is essential. Featuring a durable bearing system—with 1x thrust ball bearing and 2x sliding bearings—this swivel ensures long-lasting, smooth rotation under continuous load. Corrosion-resistant and built for high-flow performance, it is ideal for demanding pharmaceutical, food service, industrial, and automatic car wash applications. Rated for up to 2900 PSI and 250°F, it delivers outstanding reliability in harsh environments.

Applications:

• Food and beverage processing and sanitation systems

• Pharmaceutical manufacturing and CIP systems

• Industrial high-pressure cleaning and fluid transfer

• Automatic car wash rotary spray arms

Key Features:

• Robust stainless steel construction for maximum corrosion resistance

• With 1x thrust ball bearing and 2 x sliding bearings

• Smooth low-RPM operation handling both thrust and radial forces

• High-flow capacity ideal for continuous-use applications

• Thread IN: 1 1/2" NPTF | Thread OUT: 1 1/2" NPTM

• Nominal Width (NW): 1 1/2"

• Diameter: 3.33"

• Overall Length: 6.12"

• Max Pressure: 2900 PSI

• Max RPM: 30

• Max Operating Temperature: 250°F

Specs

Pressure: 2900 psi

Temperature: 250°F

RPM: Max. 30

Material Type: Stainless Steel

Inner Part: Stainless Steel

Seal: O-ring NBR

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 1 1/2"NPTF

Thread Out: G2 1 1/2"NPTM

Nominal Width (NW): 1 1/2"

Wrench Size (SW1): 1.97

Diameter 1 (D1): 3.33"

Diameter 2 (D2): 3.98

Length 1 (L1) (overall length): 6.12"

Length 2 (L2): 3.17

Length 3 (L3): 0.79

Length 4 (L4): 1.42

Length 5 (L5): 1.42

Weight: 182.9oz

The Mosmatic DGE Swivel - 34.776 is a high-performance stainless steel swivel engineered for high-pressure applications requiring dependable rotation under thrust and radial forces. Designed with a durable bearing system—including 1x thrust ball bearing and 2x sliding bearings—this swivel provides smooth, reliable operation in continuous-duty cycles. With a pressure rating of 2900 PSI and temperature resistance up to 250°F, it is corrosion resistant and ideal for use in pharmaceutical, food processing, automatic car washes, and industrial fluid systems.

Applications:

• Food and beverage sanitation and fluid transfer systems

• Pharmaceutical manufacturing and CIP applications

• Industrial high-pressure washdown and rinsing stations

• Rotary spray systems in automatic car wash setups

Key Features:

• Stainless steel construction for excellent corrosion resistance

• With 1x thrust ball bearing and 2 x sliding bearings

• Designed to handle both thrust and radial loads

• Supports high-flow, low-RPM applications

• Thread IN: 1 1/4" NPTF | Thread OUT: 1 1/4" NPTM

• Nominal Width (NW): 1 1/4"

• Diameter: 2.76"

• Overall Length: 5.65"

• Max Pressure: 2900 PSI

• Max RPM: 30

• Max Operating Temperature: 250°F

Specs

Pressure: 2900 psi

Temperature: 250°F

RPM: Max. 30

Material Type: Stainless Steel

Inner Part: Stainless Steel

Seal: O-ring NBR

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 1 1/4"NPTF

Thread Out: G2 1 1/4"NPTM

Nominal Width (NW): 1 1/4"

Wrench Size (SW1): 1.47

Diameter 1 (D1): 2.76"

Diameter 2 (D2): 3.07

Length 1 (L1) (overall length): 5.65"

Length 2 (L2): 2.84

Length 3 (L3): 0.79

Length 4 (L4): 1.18

Length 5 (L5): 1.30

Weight: 92.5oz

The Mosmatic DGE Swivel - 34.775 is a robust stainless steel swivel designed for high-pressure applications that demand durability, hygiene, and smooth rotation. Built to withstand both thrust and radial forces, it features a precision-engineered bearing system consisting of 1x thrust ball bearing and 2x sliding bearings. This swivel is corrosion resistant and built for continuous use in pharmaceutical, food service, automatic car wash, and industrial cleaning systems. With a pressure rating of 2900 PSI and a max temperature of 250°F, it delivers long-term, high-flow performance.

Applications:

• Food and beverage processing and sanitation

• Pharmaceutical clean-in-place (CIP) systems

• Industrial washdown and chemical handling

• Rotary spray assemblies in automatic car washes

Key Features:

• Stainless steel body for superior corrosion resistance

• With 1x thrust ball bearing and 2 x sliding bearings

• Supports both thrust and radial loads in high-pressure use

• Designed for high-flow, low-RPM environments

• Thread IN: 1" NPTF | Thread OUT: 1" NPTM

• Nominal Width (NW): 1"

• Diameter: 2.35"

• Overall Length: 4.84"

• Max Pressure: 2900 PSI

• Max RPM: 30

• Max Operating Temperature: 250°F

Specs

Pressure: 2900 psi

Temperature: 250°F

RPM: Max. 30

Material Type: Stainless Steel

Inner Part: Stainless Steel

Seal: O-ring NBR

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 1"NPTF

Thread Out: G2 1"NPTM

Nominal Width (NW): 1"

Wrench Size (SW1): 1.42

Diameter 1 (D1): 2.35"

Diameter 2 (D2): 2.83

Length 1 (L1) (overall length): 4.84"

Length 2 (L2): 2.52

Length 3 (L3): 0.71

Length 4 (L4): 1.18

Length 5 (L5): 1.14

Weight: 77.1oz

The Mosmatic DGE Swivel - 34.774 is a durable, high-performance stainless steel swivel designed for high-pressure, high-flow systems requiring reliable handling of both thrust and radial forces. Built with a robust bearing system—featuring 1x thrust ball bearing and 2x sliding bearings—this swivel ensures smooth, consistent rotation even under demanding continuous use. With a pressure rating of 5000 PSI and temperature tolerance up to 250°F, it’s ideal for pharmaceutical, food service, automatic car wash, and industrial cleaning applications.

Applications:

• Food and beverage production and sanitation systems

• Pharmaceutical clean-in-place (CIP) operations

• High-pressure washdown and fluid systems in industry

• Rotary spray systems in automatic car washes

Key Features:

• Corrosion-resistant stainless steel construction

• With 1x thrust ball bearing and 2 x sliding bearings

• Manages both thrust and radial forces under high pressure

• Smooth low-RPM operation with high-flow efficiency

• Thread IN: 3/4" NPTF | Thread OUT: 3/4" NPTM

• Nominal Width (NW): 3/4"

• Diameter: 1.97"

• Overall Length: 4.35"

• Max Pressure: 5000 PSI

• Max RPM: 30

• Max Operating Temperature: 250°F

Specs

Pressure: 5000 psi

Temperature: 250°F

RPM: Max. 30

Material Type: Stainless Steel

Inner Part: Stainless Steel

Seal: O-ring NBR

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 3/4"NPTF

Thread Out: G2 3/4"NPTM

Nominal Width (NW): 3/4"

Wrench Size (SW1): 1.06

Diameter 1 (D1): 1.97"

Diameter 2 (D2): 1.97

Length 1 (L1) (overall length): 4.35"

Length 2 (L2): 2.40

Length 3 (L3): 0.63

Length 4 (L4): 0.75

Length 5 (L5): 0.87

Weight: 35.7oz
