Mosmatic DGS Swivel - 30.153 - G1 3/8"NPTF G2 3/8"NPTM

Description

The Mosmatic DGS Swivel 30.153 is a premium brass, nickel-plated swivel designed for high and low pressure cleaning systems, hose connections, and hydraulic applications. Built for durability and smooth operation, this swivel ensures low torque performance under full pressure, ideal for commercial and industrial setups.

Engineered with sealed stainless steel bearings—including one thrust and one radial ball bearing—this swivel offers exceptional rotational efficiency and longevity. The integrated O-ring NBR sealing system (with optional EPDM or FKM materials) ensures tight sealing even in challenging environments.

Applications

• High and low-pressure hose connections

• Ceiling and wall-mounted booms

• Hydraulic equipment

• Commercial and industrial cleaning

• Automatic car washes

• Hose reels and rotating arms

Key Features

• Model: Mosmatic DGS 30.153

• Material: Brass, nickel-plated

• Thread IN (G1): 3/8" NPTF

• Thread OUT (G2): 3/8" NPTM

• Seal System: O-ring NBR (optional EPDM or FKM)

• Bearings: 1x thrust + 1x radial ball bearing

• Low Torque: Smooth rotation at full pressure

• Maintenance-Free: Sealed stainless steel bearing system

• Overall Diameter: 0.98”

• Overall Length: 2.36”

• Nominal Width (NW): 1/4”

• Wrench Size (SW): 0.87”

• Max Pressure: 4000 PSI

• Max RPM: 30

• Max Temperature: 250°F



Specs

Pressure: 4000 psi (27.5 MPa)

Temperature: 250°F

RPM: max 30 rpm

Material Type: Brass, Nickel plated

Inner Part: Stainless steel

Seal: O-ring NBR (optional: EPDM or FKM)

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 3/8" NPTF

Thread Out: G2 3/8" NPTM

Nominal Width (NW): 1/4”

Wrench Size 1 (SW1): 0.87"

Wrench Size 2 (SW2): 0.75"

Length 1 (L1) (overall length) : 2.36"

Lenght 2 (L2): 0.47"

Diameter (D) (overall diameter): 0.98"

Weight: 4.6 oz
