Mosmatic DYG Swivel - 90 Degrees - 57.453 - G1 3/8"NPTF G2 3/8"NPTM

The Mosmatic DYG Swivel 57.453 (90-degree configuration) is a high-quality brass swivel designed for high-pressure, self-rotating cleaning systems. Featuring a durable nickel-plated finish and corrosion-resistant construction, this swivel is ideal for surface cleaners, parts washers, and tire cleaning equipment. It includes a precision triple bearing system—two radial ball bearings and one thrust ball bearing—for smooth, efficient rotation under pressure. The integrated carbide seal system ensures superior leak protection, while the 90° bulkhead design allows for secure, space-efficient installation. Built to deliver long-lasting, maintenance-free performance in demanding environments.

Applications

• Surface cleaners

• Parts washers

• Tire and wheel cleaning systems

• High-pressure rotary spray systems

• Industrial and commercial cleaning equipment

Key Features

• Durable brass body with corrosion-resistant nickel plating

• 90° swivel design for compact and vertical installations

• Triple bearing system: 2x radial, 1x thrust ball bearing

• Carbide seal system for high-performance sealing and wear resistance

• Maintenance-free operation

• Bulkhead fitting for secure, fixed mounting

• Thread IN: 3/8” NPTF | Thread OUT: 3/8” NPTM

• Max Pressure: 4000 PSI

• Max RPM: 2000

• Max Temperature: 250°F

• Overall Diameter: 1.34”

• Overall Length: 3.30”

• Nominal Width (NW): 1/4”

• Wrench Size (SW): 0.87”

Pressure: 4000 psi

Temperature: 250°

RPM: max 2,000 rpm

Material Type: Brass, Nickel Plated

Inner Part: Stainless steel

Seal: Carbide

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 3/8” NPTF

Thread Out: G2 3/8” NPTM

Nominal Width (NW): 1/4”

Wrench Size 1 (SW1): 0.87"

Wrench Size 2 (SW2): 0.75"

Wrench Size 3 (SW3): 1.34"

 Diameter (D) (overall diameter): 1.34"

Length 1 (L1) (overall length) : 3.30

Length 2 (L2) : 0.47

Weight: 10.7 oz
